Professional Applications

The integrated parabolic reflector makes it ideal for scenic lighting in theaters and auditoriums, where a medium beam is required to cover intermediate distances. It is a fundamental component for photography sets and accent lighting in exhibitions and museums, as well as being the standard replacement lamp for PAR 56 cans used by live event production services.

Key Advantages

Unlike standard lamps, the OMNILUX model ensures an operational lifespan of 2000 hours, drastically reducing maintenance cycles and the need for frequent replacements at height. The 23° (MFL) light emission offers the perfect balance between beam concentration and coverage width, avoiding dispersive halos and maintaining optimal center intensity for precision aiming.

FAQ for Installers and Professionals

What is the required protection rating for the housing fixture?

This lamp is designed to operate within standard PAR 56 fixtures. For outdoor use (architectural applications), the lighting body must provide a minimum IP65 protection rating to shield the GX16d contacts from moisture and corrosion.

Is this light source dimmable?

Yes, as it is a traditional filament halogen lamp, it is fully compatible with phase-cut control systems (traditional dimmer racks and DMX systems with external dimmers) without flickering.

Can I directly replace an NSP or WFL version with this lamp?

Absolutely. The GX16d base and physical dimensions (ø 178 mm) are identical. Switching to a 23° MFL version allows for a softer beam compared to the NSP (Narrow Spot), making it ideal for achieving homogeneous coverage without excessive "hot spots."
